מחיר ₪ 571 ILS 10/7/2027 In stock https://www.pccenter.co.il/product/נתב-אלחוטימודם-סלולרי-cudy-lt700-eu-il-4g CUDY 1040096 1040096
| CPU | Chipset | MT7621 |
|---|---|---|
| CPU Details | 580 MHZ Single-Core, MIPS24KEC | |
| Memory/Storage | Flash/ROM | 16 MB (128 Mbit) NOR |
| DDR/RAM | 128 MB (1 Gbit) DDR3 | |
| Cellular | Celluar Standards | 4G LTE Cat. 6 |
| Cellular Antennas | 4× Detachable | |
| Detachable Cellular Antennas Connector | SMA Female | |
| SIM Options | 2× Nano SIM Slots | |
| Available Versions | EU, US | |
| EU Version Cellular | Suitable Region | Europe, Middle East, Africa |
| EU Max DL Speed | 300 Mbps (LTE-FDD), 226 Mbps (LTE-TDD) | |
| EU Max UL Speed | 50 Mbps (LTE-FDD), 28 Mbps (LTE-TDD) | |
| Advanced | DL 2CA, DL 2×2 MIMO | |
| Celluar Bands | LTE-FDD: B1/3/5/7/8/20/28/32 LTE-TDD: B38/40/41 WCDMA: B1/3/5/8 |
|
| US Version Cellular | Suitable Region | United States, Canada |
| Max DL Speed | 300 Mbps (LTE-FDD), 226 Mbps (LTE-TDD) | |
| Max UL Speed | 50 Mbps (LTE-FDD), 28 Mbps (LTE-TDD) | |
| Advanced | DL 2CA, DL 4×4 MIMO | |
| Celluar Bands | LTE-FDD: B2/4/5/7/12/13/14/25/26/29/30/66/71 LTE-TDD: B41/48 |
|
| Wireless | 5 GHz Wi-Fi Speed | 867 Mbps |
| 2.4 GHz Wi-Fi Speed | 300 Mbps | |
| 5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| Wi-Fi Antennas | 2× Fixed | |
| 5 GHz Anntenna Gain Max | 5.18 dBi | |
| 2.4 GHz Antenna Gain Max | 3.16 dBi | |
| Detachable Wi-Fi Antennas Connector | RP-SMA Female | |
| FEM or PA/LNA |
|
|
| Wi-Fi Transmission Power |
|
|
| Range Performance | Max: 170 m (558 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. |
|
| Wall Performance | One wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') |
|
| Interfaces | Physical Buttons |
|
| Gigabit RJ45 Ports | 4 | |
| Ethernet Notes | One port supports WAN/LAN configuration, and the rest are LAN ports | |
| LED |
|
|
| Power Input | DC Jack | |
| Power | Power Methods | DC |
| DC | 12V 1A | |
| Power Adapter | Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC |
|
| Max Power Consumption (W) | 11.2W | |
| Idle Power Consumption (W) | 3.6W | |
| Reliability | ESD Contact Protection | 4kV |
| ESD Air Protection | 8kV | |
| Environment | Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
|
| Package Content |
|
|
| Mechanical | Dimension | 253×152.5×48.2 mm 9.96×6×1.9 inches |
| Product Weight | 536 g (18.91 oz.) | |
| Installation |
|
|
| Ordering Information | Retail Package Weight |
|
| Retail Package Dimension | 393×250×60 mm 15.47×9.84×2.36 inches |
|
| Units per Carton | 10 | |
| Carton Net Weight |
|
|
| Carton Gross Weight |
|
|
| Carton Dimension |
40.8×33×52.5 cm |
|
| Model Version | LT700 1.0 | |
|---|---|---|
| Wireless | Wi-Fi Standards | Wi-Fi 5 |
| Max Wi-Fi Modulation | 256-QAM | |
| Wi-Fi Efficiency | MU-MIMO | |
| Wi-Fi Efficiency Note | MU-MIMO available on 5 GHz | |
| Max Capacity | 128 | |
| Recommended Client Upper Limit | 50 | |
| Max Wi-Fi Channel Width | 80 MHz | |
| Wi-Fi Security | WPA-PSK (WPA/WPA2/WPA3) | |
| Guest Network | 2.4 GHz, 5 GHz | |
| WPS | True | |
| General | Operation Modes |
|
| Mesh | Cudy Mesh Main | |
| Mesh Backhaul |
|
|
| Cellular APN |
|
|
| Cellular Mode |
|
|
| WAN Mode |
|
|
| Internet Failover Sequence |
|
|
| Network | QoS | Per-User Rate Limiting |
| DHCP |
|
|
| IP Versions | IPv4/IPv6 | |
| IPv6 Protocols |
|
|
| IPTV/VLAN |
|
|
| TTL Customization |
|
|
| IGMP |
|
|
| Forwarding |
|
|
| Firewall |
|
|
| Application Layer Gateway |
|
|
| Utilities | VPN Server |
|
| VPN Client |
|
|
| DNS Options |
|
|
| DNS over TLS Providers |
|
|
| Wake on LAN | True | |
| Online Detection | True | |
| Management | All Devices Management |
|
| Per-Devices Management |
|
|
| Content Management |
|
|
| System | Local Control Method |
|
| Remote Control Method |
|
|
| Firmware Upgrade |
|
|
| Diagnostic Tools |
|
|
| Languages |
|
|
| Reliability |
|
|
| Dashboard | Panel |
|
| Charts |
|
|
